| Manufacturer Part Number: | 749196331 |
|---|---|
| Manufacturer: | Wurth Electronics Inc |
| Product Category: | Switching Converter, SMPS Transformers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | TRANSFORMER 9.3UH .97A SMD |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 749196331 Datasheet |
| Internal Part Number | 898-749196331 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 749196331.igs 749196331.stp | |
| Category | Transformers | |
| Family | Switching Converter, SMPS Transformers | |
| Manufacturer | Wurth Electronics Inc | |
| Series | WE-FLEX | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Configurable (For DC/DC) | |
| Applications | Flyback Converters | |
| Intended Chipset | - | |
| Voltage - Primary | - | |
| Voltage - Auxillary | - | |
| Voltage - Isolation | 500VDC | |
| Frequency | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Size / Dimension | 17.50mm L x 16.00mm W | |
| Height - Seated (Max) | 8.30mm | |
| Chipset Manufacturer | - | |
| Standard Package | 300 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 749196331 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
749196331 is in stock for immediate shipping now. We are the distributor of Wurth Electronics Inc all series components. The condition of 749196331 is new and unused, you can buy 749196331 Wurth Electronics Inc with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 749196331.
