744773039

744773039
Manufacturer Part Number:744773039
Manufacturer:
Product Category:Fixed Inductors
Available Quantity:10510 Pieces
Unit Price:Quote by Email
Description:3.9µH Unshielded Wirewound Inductor 1.88A 94 mOhm Max Nonstandard
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 744773039 Datasheet
744773039´s Parameters
Internal Part Number898-744773039
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
3D ModelWE-PD2-4532.igs
WE-PD2-4532.stp
Online Catalog WE-PD2 and WE-PD2A Series
CategoryInductors, Coils, Chokes
FamilyFixed Inductors
ManufacturerWurth Electronics Inc
SeriesWE-PD2
PackagingTape & Reel (TR)
Part StatusActive
TypeWirewound
Material - CoreFerrite
Inductance3.9µH
Tolerance±20%
Current Rating1.88A
Current - Saturation2.57A
ShieldingUnshielded
DC Resistance (DCR)94 mOhm Max
Q @ Freq-
Frequency - Self Resonant50MHz
Ratings-
Operating Temperature-40°C ~ 125°C
Frequency - Test10kHz
Mounting TypeSurface Mount
Package / CaseNonstandard
Size / Dimension0.177" L x 0.157" W (4.50mm x 4.00mm)
Height - Seated (Max)0.138" (3.50mm)
Standard Package 1,500
Weight0.001 KG
ApplicationEmail for details
Replacement Part744773039
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

744773039 is in stock for immediate shipping now. We are the distributor of Wurth Electronics Inc all series components. The condition of 744773039 is new and unused, you can buy 744773039 Wurth Electronics Inc with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 744773039.
