| Manufacturer Part Number: | 744029006 |
|---|---|
| Manufacturer: | Wurth Electronics Inc |
| Product Category: | Fixed Inductors |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 6.8µH Shielded Wirewound Inductor 820mA 300 mOhm Max Nonstandard |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 744029006 Datasheet |
| Internal Part Number | 898-744029006 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Spice Model Library | |
| Featured Product | Tiny Power Inductors | |
| 3D Model | WE-TPC_2813.igs WE-TPC_2813.stp | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Manufacturer | Wurth Electronics Inc | |
| Series | WE-TPC | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 6.8µH | |
| Tolerance | ±30% | |
| Current Rating | 820mA | |
| Current - Saturation | 650mA | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 300 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | 55MHz | |
| Ratings | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.110" L x 0.110" W (2.80mm x 2.80mm) | |
| Height - Seated (Max) | 0.059" (1.50mm) | |
| Standard Package | 1,200 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 744029006 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
744029006 is in stock for immediate shipping now. We are the distributor of Wurth Electronics Inc all series components. The condition of 744029006 is new and unused, you can buy 744029006 Wurth Electronics Inc with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 744029006.
