Manufacturer Part Number: | 70AAJ-5-F1 |
---|---|
Manufacturer: | Bourns Inc. |
Product Category: | Rectangular Connectors - Spring Loaded |
Available Quantity: | 9478 Pieces |
Unit Price: | Quote by Email |
Description: | 5 Position Spring Compression Contact, Female Connector Surface Mount |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 70AAJ-5-F1 Datasheet |
Internal Part Number | 898-70AAJ-5-F1 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | 70AA 5PIN Material Declaration | |
PCN Design/Specification | 70AD,70AA,70AB Series Aug/2014 | |
PCN Assembly/Origin | Facility Transfer Jul/2012 | |
PCN Packaging | Min/Mult Order Quantity Apr/2013 70AA Male, 70AA Female Models Sept/2013 | |
Online Catalog | 70AA Series | |
Category | Connectors, Interconnects | |
Family | Rectangular Connectors - Spring Loaded | |
Manufacturer | Bourns Inc. | |
Series | 70AA | |
Packaging | Tube | |
Part Status | Active | |
Connector Type | Compression Contact, Female | |
Number of Contacts | 5 | |
Pitch | 0.100" (2.54mm) | |
Number of Rows | 1 | |
Row Spacing | - | |
Mounting Type | Surface Mount | |
Material | Copper Alloy | |
Contact Finish | Gold | |
Contact Finish Thickness | 30µin (0.76µm) | |
Standard Package | 24 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 70AAJ-5-F1 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
70AAJ-5-F1 is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of 70AAJ-5-F1 is new and unused, you can buy 70AAJ-5-F1 Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 70AAJ-5-F1.
