Manufacturer Part Number: | 70232-111LF |
---|---|
Manufacturer: | Amphenol FCI |
Product Category: | Backplane Connectors - Specialized |
Available Quantity: | 10065 Pieces |
Unit Price: | Quote by Email |
Description: | CONN HEADER 24POS VERT PCB PRSFT |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 70232-111LF Datasheet |
Internal Part Number | 898-70232-111LF | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
PCN Design/Specification | New Alloy 02/Aug/2013 | |
PCN Assembly/Origin | Multiple Devices Location Change 29/Jan/2015 | |
PCN Other | Multiple Devices Material 25/Nov/2014 Multiple Devices Material Reversal 22/Apr/2015 | |
Online Catalog | Metral® Series | |
Category | Connectors, Interconnects | |
Family | Backplane Connectors - Specialized | |
Manufacturer | Amphenol FCI | |
Series | Metral® | |
Packaging | Tube | |
Part Status | Active | |
Connector Usage | - | |
Connector Type | Header, Male Pins | |
Connector Style | - | |
Number of Positions | 24 | |
Number of Positions Loaded | All | |
Pitch | 0.079" (2.00mm) | |
Number of Rows | 4 | |
Number of Columns | - | |
Mounting Type | Through Hole | |
Termination | Press-Fit | |
Contact Layout, Typical | - | |
Features | - | |
Contact Finish | Gold | |
Contact Finish Thickness | 30µin (0.76µm) | |
Color | Natural | |
Current Rating | 1A | |
Material Flammability Rating | UL94 V-0 | |
Operating Temperature | -55°C ~ 125°C | |
Voltage Rating | - | |
Standard Package | 48 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 70232-111LF | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
70232-111LF is in stock for immediate shipping now. We are the distributor of Amphenol FCI all series components. The condition of 70232-111LF is new and unused, you can buy 70232-111LF Amphenol FCI with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 70232-111LF.
