Manufacturer Part Number: | 7006-H-500 |
---|---|
Manufacturer: | LEDdynamics Inc. |
Product Category: | LED Drivers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 500mA Constant Current LED Driver AC DC Converter Topology 1 Output |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 7006-H-500 Datasheet |
Internal Part Number | 898-7006-H-500 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Design Resources | Lighting Product Selector | |
Category | Power Supplies - External/Internal (Off-Board) | |
Family | LED Drivers | |
Manufacturer | LEDdynamics Inc. | |
Series | BuckBullet™ 7006 | |
Part Status | Active | |
Type | Constant Current | |
Topology | AC DC Converter | |
Number of Outputs | 1 | |
Voltage - Input (Min) | 8VAC | |
Voltage - Input (Max) | 24VAC | |
Voltage - Output | - | |
Current - Output (Max) | 500mA | |
Power (Watts) | - | |
Voltage - Isolation | - | |
Dimming | - | |
Features | SCP | |
Ratings | - | |
Operating Temperature | -40°C ~ 60°C | |
Efficiency | 95% | |
Termination Style | Wire Leads | |
Size / Dimension | 2.00" L x 0.50" Dia (51.0mm x 13.0mm) | |
Mounting Type | Chassis Mount | |
Approvals | - | |
Weight | 0.001 KG | |
Standard Package | 10 | |
Application | Email for details | |
Replacement Part | 7006-H-500 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
7006-H-500 is in stock for immediate shipping now. We are the distributor of LEDdynamics Inc. all series components. The condition of 7006-H-500 is new and unused, you can buy 7006-H-500 LEDdynamics Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 7006-H-500.
