66226-012LF

66226-012LF
Manufacturer Part Number:66226-012LF
Manufacturer:
Product Category:FFC, FPC (Flat Flexible) Connectors
Available Quantity:9726 Pieces
Unit Price:Quote by Email
Description:12 Position FFC Connector Header 0.100" (2.54mm) Free Hanging (In-Line)
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 66226-012LF Datasheet
66226-012LF´s Parameters
Internal Part Number898-66226-012LF
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Product Training ModulesFlat Flex Connector Overview
Featured ProductFFC and FPC Connectors
PCN PackagingTray slots 02/Sept/2011
EDA / CAD Models Download from Accelerated Designs
CategoryConnectors, Interconnects
FamilyFFC, FPC (Flat Flexible) Connectors
ManufacturerAmphenol FCI
SeriesClincher™
PackagingTray
Part StatusActive
Flat Flex TypeFFC
Mounting TypeFree Hanging (In-Line)
Connector/Contact TypeHeader
Number of Positions12
Pitch0.100" (2.54mm)
TerminationIDC
FFC, FCB Thickness0.33mm
Height Above Board-
Locking Feature-
Cable End Type-
Contact MaterialCopper Nickel Alloy
Contact FinishTin
Housing MaterialThermoplastic
Actuator Material-
Features-
Voltage Rating500V
Operating Temperature-65°C ~ 105°C
Material Flammability RatingUL94 V-0
Current Rating2A
Standard Package 30
Weight0.001 KG
ApplicationEmail for details
Replacement Part66226-012LF
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

66226-012LF is in stock for immediate shipping now. We are the distributor of Amphenol FCI all series components. The condition of 66226-012LF is new and unused, you can buy 66226-012LF Amphenol FCI with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 66226-012LF.
