Manufacturer Part Number: | 59170-1-S-00-D |
---|---|
Manufacturer: | Littelfuse Inc. |
Product Category: | Magnetic, Reed Switches |
Available Quantity: | 61510 Pieces |
Unit Price: | Quote by Email |
Description: | Molded Body Reed Switch SPST-NO 10 ~ 15AT Operate Range 10W 350mA (AC), 500mA (DC) 140V Surface Mount |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 59170-1-S-00-D Datasheet |
Internal Part Number | 898-59170-1-S-00-D | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Other Related Documents | Ampere*turn vs. mT & Gauss Appl Note Handling of Reed Sensors, Relays, Switches Appl Note Reed Switch, Sensor Activation Appl Note | |
Online Catalog | 59170 Series | |
Category | Switches | |
Family | Magnetic, Reed Switches | |
Manufacturer | Littelfuse Inc. | |
Series | 59170 | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Type | Molded Body | |
Circuit | SPST-NO | |
Operate Range | 10 ~ 15AT | |
Release Range | - | |
Current - Switching | 350mA (AC), 500mA (DC) | |
Voltage - Switching AC | 140V | |
Voltage - Switching DC | 200V | |
Power - Rated | 10W | |
Operate Time | 1ms | |
Release Time | 0.5ms | |
Mounting Type | Surface Mount | |
Termination Style | Gull Wing | |
Length - Overall | 0.640" (16.26mm) | |
Size - Body | 0.450" L x 0.090" W x 0.090" H (11.43mm x 2.29mm x 2.29mm) | |
Height Above Board | 0.095" (2.41mm) | |
Operating Temperature | -40°C ~ 125°C | |
Capacitance | 0.30pF | |
Current - Carry | 800mA (DC) | |
Standard Package | 1,500 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 59170-1-S-00-D | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
59170-1-S-00-D is in stock for immediate shipping now. We are the distributor of Littelfuse Inc. all series components. The condition of 59170-1-S-00-D is new and unused, you can buy 59170-1-S-00-D Littelfuse Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 59170-1-S-00-D.
