| Manufacturer Part Number: | 48245-000LF |
|---|---|
| Manufacturer: | Amphenol FCI |
| Product Category: | Rectangular Connectors - Contacts |
| Available Quantity: | 19010 Pieces |
| Unit Price: | Quote by Email |
| Description: | CONN SOCKET 22-26AWG CRIMP GOLD |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 48245-000LF Datasheet |
| Internal Part Number | 898-48245-000LF | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 48245-000LF.stp 48245-000LF.igs 48245-000LF.prt | |
| PCN Design/Specification | Mini, Maxi PV Plating 26/Aug/2008 Gold flash removal 27/Oct/2011 | |
| PCN Assembly/Origin | Mini, Maxi, CTW 02/may/2013 PV Terminals Location Change 11/Jun/2015 | |
| Online Catalog | Mini-PV™, Basics+ | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Contacts | |
| Manufacturer | Amphenol FCI | |
| Series | Mini-PV™, Basics+ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Type | - | |
| Pin or Socket | Socket | |
| Contact Termination | Crimp | |
| Wire Gauge | 22-26 AWG | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 15µin (0.38µm) | |
| Standard Package | 10,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 48245-000LF | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
48245-000LF is in stock for immediate shipping now. We are the distributor of Amphenol FCI all series components. The condition of 48245-000LF is new and unused, you can buy 48245-000LF Amphenol FCI with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 48245-000LF.
