Manufacturer Part Number: | 46557-3545 |
---|---|
Manufacturer: | Molex, LLC |
Product Category: | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 120 Position Connector High Density Array, Female Surface Mount Gold |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 46557-3545 Datasheet |
Internal Part Number | 898-46557-3545 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Video File | Molex RF Connectors | Digi-Key Daily | |
RoHS Information | 46557-3545 Cert of Compliance | |
3D Model | 46557-3545.stp 46557-3545.igs 46557-3545.prt | |
Online Catalog | SEARAY™ Series | |
Category | Connectors, Interconnects | |
Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
Manufacturer | Molex Connector Corporation | |
Series | SEARAY™ 46557 | |
Packaging | Tape & Reel (TR) | |
Part Status | Active | |
Connector Type | High Density Array, Female | |
Number of Positions | 120 | |
Pitch | 0.050" (1.27mm) | |
Number of Rows | 4 | |
Mounting Type | Surface Mount | |
Features | Board Guide | |
Contact Finish | Gold | |
Contact Finish Thickness | 30µin (0.76µm) | |
Mated Stacking Heights | 10mm, 10.5mm, 11mm, 11.5mm, 12.5mm, 13mm, 15mm | |
Height Above Board | 0.317" (8.05mm) | |
Standard Package | 210 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 46557-3545 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
46557-3545 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 46557-3545 is new and unused, you can buy 46557-3545 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 46557-3545.
