Manufacturer Part Number: | 4652-RC |
---|---|
Manufacturer: | Bourns Inc. |
Product Category: | Fixed Inductors |
Available Quantity: | 9576 Pieces |
Unit Price: | Quote by Email |
Description: | 1mH Unshielded Wirewound Inductor 160mA 19 Ohm Max Axial |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 4652-RC Datasheet |
Internal Part Number | 898-4652-RC | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
3D Model | 4652-RC.stp | |
PCN Obsolescence/ EOL | 4600 Varnished Choke Series 12/May/2016 | |
PCN Part Status Change | Multiple Devices Optimization Plans Jul/2016 | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | 4600 Series | |
Category | Inductors, Coils, Chokes | |
Family | Fixed Inductors | |
Manufacturer | Bourns Inc. | |
Series | 4600 | |
Packaging | Bulk | |
Part Status | Last Time Buy | |
Type | Wirewound | |
Material - Core | Phenolic | |
Inductance | 1mH | |
Tolerance | ±5% | |
Current Rating | 160mA | |
Current - Saturation | - | |
Shielding | Unshielded | |
DC Resistance (DCR) | 19 Ohm Max | |
Q @ Freq | 59 @ 252kHz | |
Frequency - Self Resonant | 3.7MHz | |
Ratings | - | |
Operating Temperature | -55°C ~ 125°C | |
Frequency - Test | 252kHz | |
Mounting Type | Through Hole | |
Package / Case | Axial | |
Size / Dimension | 0.560" Dia x 0.875" L (14.22mm x 22.22mm) | |
Height - Seated (Max) | - | |
Standard Package | 72 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 4652-RC | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
4652-RC is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of 4652-RC is new and unused, you can buy 4652-RC Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 4652-RC.
