| Manufacturer Part Number: | 4609H-701-101/101L |
|---|---|
| Manufacturer: | Bourns Inc. |
| Product Category: | EMI/RFI Filters (LC, RC Networks) |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | RC EMI Filter 1st Order Low Pass 8 Channel R = 100 Ohms, C = 100pF 9-SIP |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 4609H-701-101/101L Datasheet |
| Internal Part Number | 898-4609H-701-101/101L | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 4609H-701.stp | |
| PCN Obsolescence/ EOL | 700 Series RC Terminator Network,900 Series Cap Dec/2015 | |
| Category | Filters | |
| Family | EMI/RFI Filters (LC, RC Networks) | |
| Manufacturer | Bourns Inc. | |
| Series | 700 | |
| Packaging | Bulk | |
| Part Status | Obsolete | |
| Type | Low Pass | |
| Filter Order | 1st | |
| Technology | RC | |
| Number of Channels | 8 | |
| Center / Cutoff Frequency | - | |
| Attenuation Value | - | |
| Resistance - Channel (Ohms) | 100 | |
| Current | - | |
| Values | R = 100 Ohms, C = 100pF | |
| ESD Protection | No | |
| Operating Temperature | -30°C ~ 85°C | |
| Applications | General Purpose | |
| Voltage - Rated | 50V | |
| Mounting Type | Through Hole | |
| Package / Case | 9-SIP | |
| Size / Dimension | 0.902" L x 0.150" W (22.90mm x 3.81mm) | |
| Height | 0.335" (8.50mm) | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 4609H-701-101/101L | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
4609H-701-101/101L is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of 4609H-701-101/101L is new and unused, you can buy 4609H-701-101/101L Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 4609H-701-101/101L.
