| Manufacturer Part Number: | 450-0103C |
|---|---|
| Manufacturer: | LSR |
| Product Category: | RF Transceiver Modules |
| Available Quantity: | 17219 Pieces |
| Unit Price: | Quote by Email |
| Description: | RF TXRX MOD BLUETOOTH TRACE ANT |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 4 (72 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 450-0103C Datasheet |
| Internal Part Number | 898-450-0103C | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector IoT Product Selector | |
| Featured Product | LSR - TiWi-uB1™ Bluetooth® Smart Modules | |
| Online Catalog | 450-0103C | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver Modules | |
| Manufacturer | LSR | |
| Series | TiWi-uB1 | |
| Packaging | Cut Strip | |
| Part Status | Active | |
| RF Family/Standard | Bluetooth | |
| Protocol | Bluetooth v4.0 | |
| Modulation | GFSK, MSK | |
| Frequency | 2.4GHz | |
| Data Rate | 2Mbps | |
| Power - Output | 0dBm | |
| Sensitivity | -94dBm | |
| Serial Interfaces | I²C, SPI | |
| Antenna Type | Integrated, Trace | |
| Memory Size | 256kB Flash, 8kB RAM | |
| Voltage - Supply | 2 V ~ 3.6 V | |
| Current - Receiving | 15.7mA ~ 28.1mA | |
| Current - Transmitting | 12mA ~ 21.1mA | |
| Mounting Type | Surface Mount | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | Module | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 450-0103C | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
450-0103C is in stock for immediate shipping now. We are the distributor of LSR all series components. The condition of 450-0103C is new and unused, you can buy 450-0103C LSR with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 450-0103C.
