| Manufacturer Part Number: | 43223-8140 |
|---|---|
| Manufacturer: | Molex, LLC |
| Product Category: | Modular Connectors - Jacks |
| Available Quantity: | 9033 Pieces |
| Unit Price: | Quote by Email |
| Description: | Jack Modular Connector 8p8c (RJ45, Ethernet) 90° Angle (Right) Unshielded Cat4 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 43223-8140 Datasheet |
| Internal Part Number | 898-43223-8140 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | Molex RF Connectors | Digi-Key Daily | |
| RoHS Information | 43223-8140 Cert of Compliance | |
| Featured Product | Modular Jacks and Plugs | |
| 3D Model | 43223-8140.stp | |
| PCN Obsolescence/ EOL | Multiple Devices 23/Jun/2016 | |
| Category | Connectors, Interconnects | |
| Family | Modular Connectors - Jacks | |
| Manufacturer | Molex Connector Corporation | |
| Series | 43223 | |
| Packaging | Tray | |
| Part Status | Obsolete | |
| Connector Type | Jack | |
| Number of Positions/Contacts | 8p8c (RJ45, Ethernet) | |
| Number of Ports | 4 | |
| Number of Rows | 1 | |
| Mounting Type | Through Hole | |
| Orientation | 90° Angle (Right) | |
| Termination | Solder | |
| Shielding | Unshielded | |
| Ratings | Cat4 | |
| Features | Board Lock | |
| LED Color | Does Not Contain LED | |
| Ingress Protection | - | |
| Tab Direction | Down | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Housing Material | Polyamide (PA), Nylon, Glass Filled | |
| Operating Temperature | -40°C ~ 85°C | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 43223-8140 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
43223-8140 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 43223-8140 is new and unused, you can buy 43223-8140 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 43223-8140.
