Manufacturer Part Number: | 39SB-1NB-103 |
---|---|
Manufacturer: | Bourns Inc. |
Product Category: | Rotary Potentiometers, Rheostats |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 10k Ohm 1 Gang Linear Panel Mount Potentiometer None 1 Turn Conductive Plastic 0.25W, 1/4W PC Pins |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 39SB-1NB-103 Datasheet |
Internal Part Number | 898-39SB-1NB-103 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | 39 Material Declaration | |
3D Model | 39XB-XNX-yyy.stp | |
PCN Design/Specification | Model 39 Series Spring and Rotor Design 01/Oct/2013 | |
PCN Other | Multiple Changes 01/Dec/2012 | |
Category | Potentiometers, Variable Resistors | |
Family | Rotary Potentiometers, Rheostats | |
Manufacturer | Bourns Inc. | |
Series | 39 | |
Packaging | Bulk | |
Part Status | Active | |
Taper | Linear | |
Resistance (Ohms) | 10k | |
Tolerance | ±20% | |
Number of Gangs | 1 | |
Built in Switch | None | |
Power (Watts) | 0.25W, 1/4W | |
Temperature Coefficient | - | |
Number of Turns | 1 | |
Rotation | 270° | |
Adjustment Type | Top Adjustment | |
Resistive Material | Conductive Plastic | |
Termination Style | PC Pins | |
Actuator Type | Flatted | |
Actuator Length | 0.500" (12.70mm) | |
Actuator Diameter | 0.125" (3.18mm) | |
Bushing Thread | 1/4-28 | |
Mounting Type | Panel Mount | |
Standard Package | 100 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 39SB-1NB-103 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
39SB-1NB-103 is in stock for immediate shipping now. We are the distributor of Bourns Inc. all series components. The condition of 39SB-1NB-103 is new and unused, you can buy 39SB-1NB-103 Bourns Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 39SB-1NB-103.
