Manufacturer Part Number: | 39544-3008 |
---|---|
Manufacturer: | Molex, LLC |
Product Category: | Terminal Blocks - Wire to Board |
Available Quantity: | 9583 Pieces |
Unit Price: | Quote by Email |
Description: | 8 Position Wire to Board Terminal Block Horizontal with Board 0.200" (5.08mm) Through Hole |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 39544-3008 Datasheet |
Internal Part Number | 898-39544-3008 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Video File | Molex RF Connectors | Digi-Key Daily | |
RoHS Information | 39544-3008 Cert of Compliance | |
3D Model | 39544-3008.stp | |
Online Catalog | Eurostyle™ Series | |
Category | Connectors, Interconnects | |
Family | Terminal Blocks - Wire to Board | |
Manufacturer | Molex Connector Corporation | |
Series | Eurostyle™ ESE 39544 | |
Packaging | Bulk | |
Part Status | Active | |
Number of Levels | 1 | |
Positions Per Level | 8 | |
Pitch | 0.200" (5.08mm) | |
Mating Orientation | Horizontal with Board | |
Current | 15A | |
Voltage | 300V | |
Wire Gauge | 12-30 AWG | |
Mounting Type | Through Hole | |
Wire Termination | Screw - Rising Cage Clamp | |
Features | - | |
Color | Black | |
Operating Temperature | -40°C ~ 105°C | |
Housing Material | Polyamide (PA66), Nylon 6/6 | |
Contact Material - Plating | Brass - Tin Plated | |
Clamp Material - Plating | Brass - Nickel Plated | |
Screw Material - Plating | Steel - Zinc Plated | |
Torque - Screw | 0.51 Nm (4.5 Lb-In) | |
Screw Thread | M3 | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 39544-3008 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
39544-3008 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 39544-3008 is new and unused, you can buy 39544-3008 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 39544-3008.
