| Manufacturer Part Number: | 3893-0050 |
|---|---|
| Manufacturer: | 3M |
| Product Category: | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 150 Position Connector Stacking Compression Surface Pressure with Screw Lock Gold |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 3893-0050 Datasheet |
| Internal Part Number | 898-3893-0050 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | 3893-0050,3882-100A 12/Dec/2014 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine | |
| Manufacturer | 3M | |
| Series | 389 | |
| Packaging | Bulk | |
| Part Status | Obsolete | |
| Connector Type | Stacking Compression | |
| Number of Positions | 150 | |
| Pitch | 0.050" (1.27mm) | |
| Number of Rows | 4 | |
| Mounting Type | Surface Pressure with Screw Lock | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Mated Stacking Heights | - | |
| Height Above Board | 0.343" (8.70mm) | |
| Standard Package | 10 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 3893-0050 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
3893-0050 is in stock for immediate shipping now. We are the distributor of 3M all series components. The condition of 3893-0050 is new and unused, you can buy 3893-0050 3M with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 3893-0050.
