| Manufacturer Part Number: | 3569 |
|---|---|
| Manufacturer: | Keystone Electronics |
| Product Category: | Fuseholders |
| Available Quantity: | 9812 Pieces |
| Unit Price: | Quote by Email |
| Description: | FUSE CLIP BLADE 500V 15A SMD |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 3569 Datasheet |
| Internal Part Number | 898-3569 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Compliance Statement | |
| Online Catalog | Automotive Blade Fuse Holders | |
| Category | Circuit Protection | |
| Family | Fuseholders | |
| Manufacturer | Keystone Electronics | |
| Series | - | |
| Part Status | Active | |
| Fuseholder Type | Clip | |
| Fuse Type | Blade | |
| For Use With/Related Products | MINI ATC, MINI ATO | |
| Fuse Size | 0.43" L x 0.15" W x 0.64" H (10.92mm x 3.81mm x 16.25mm) | |
| Number of Circuits | 1 | |
| Voltage | 500V | |
| Current Rating | 15A | |
| Mounting Type | Surface Mount | |
| Orientation | - | |
| Termination Style | SMD (SMT) Tab | |
| Contact Material | Brass | |
| Contact Finish | Tin Nickel | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 3569 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
3569 is in stock for immediate shipping now. We are the distributor of Keystone Electronics all series components. The condition of 3569 is new and unused, you can buy 3569 Keystone Electronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 3569.
