| Manufacturer Part Number: | 3566 |
|---|---|
| Manufacturer: | Keystone Electronics |
| Product Category: | Fuseholders |
| Available Quantity: | 24096 Pieces |
| Unit Price: | Quote by Email |
| Description: | FUSE CLIP CARTRIDGE 30A PCB |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 3566 Datasheet |
| Internal Part Number | 898-3566 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Compliance Statement | |
| Online Catalog | Press-In Fuse Clips | |
| Category | Circuit Protection | |
| Family | Fuseholders | |
| Manufacturer | Keystone Electronics | |
| Series | - | |
| Part Status | Active | |
| Fuseholder Type | Clip | |
| Fuse Type | Cartridge | |
| For Use With/Related Products | 13/32" Dia | |
| Fuse Size | 13/32" Dia (10.3mm) | |
| Number of Circuits | 1 | |
| Voltage | - | |
| Current Rating | 30A | |
| Mounting Type | PCB | |
| Orientation | Horizontal | |
| Termination Style | PC Pin | |
| Contact Material | Brass | |
| Contact Finish | Tin | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 3566 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
3566 is in stock for immediate shipping now. We are the distributor of Keystone Electronics all series components. The condition of 3566 is new and unused, you can buy 3566 Keystone Electronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 3566.
