| Manufacturer Part Number: | 3522-2 |
|---|---|
| Manufacturer: | Keystone Electronics |
| Product Category: | Fuseholders |
| Available Quantity: | 103547 Pieces |
| Unit Price: | Quote by Email |
| Description: | FUSE CLIP BLADE 500V 20A PCB |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 3522-2 Datasheet |
| Internal Part Number | 898-3522-2 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Compliance Statement | |
| Online Catalog | Automotive Blade Fuse Holders | |
| Category | Circuit Protection | |
| Family | Fuseholders | |
| Manufacturer | Keystone Electronics | |
| Series | - | |
| Part Status | Active | |
| Fuseholder Type | Clip | |
| Fuse Type | Blade | |
| For Use With/Related Products | ATC, ATO 257 | |
| Fuse Size | 1.15" L x 0.35" W x 1.35" H (29.21mm x 8.85mm x 34.29mm) | |
| Number of Circuits | 2 | |
| Voltage | 500V | |
| Current Rating | 20A | |
| Mounting Type | PCB | |
| Orientation | Vertical | |
| Termination Style | PC Pin | |
| Contact Material | Brass | |
| Contact Finish | Tin Nickel | |
| Standard Package | 100 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 3522-2 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
3522-2 is in stock for immediate shipping now. We are the distributor of Keystone Electronics all series components. The condition of 3522-2 is new and unused, you can buy 3522-2 Keystone Electronics with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 3522-2.
