| Manufacturer Part Number: | 1N824-E3 |
|---|---|
| Manufacturer: | Microsemi Corporation |
| Product Category: | Diodes - Zener - Single |
| Available Quantity: | 9282 Pieces |
| Unit Price: | Quote by Email |
| Description: | Zener Diode 6.2V 500mW ±5% Through Hole DO-35 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 1N824-E3 Datasheet |
| Internal Part Number | 898-1N824-E3 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Manufacturer | Microsemi Corporation | |
| Series | Military, MIL-PRF-19500/159 | |
| Packaging | Bulk | |
| Part Status | Active | |
| Voltage - Zener (Nom) (Vz) | 6.2V | |
| Tolerance | ±5% | |
| Power - Max | 500mW | |
| Impedance (Max) (Zzt) | 15 Ohm | |
| Current - Reverse Leakage @ Vr | 2µA @ 3V | |
| Voltage - Forward (Vf) (Max) @ If | - | |
| Operating Temperature | -55°C ~ 175°C | |
| Mounting Type | Through Hole | |
| Package / Case | DO-204AH, DO-35, Axial | |
| Supplier Device Package | DO-35 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 1N824-E3 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
1N824-E3 is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of 1N824-E3 is new and unused, you can buy 1N824-E3 Microsemi Corporation with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 1N824-E3.
