1N5418US

1N5418US
Manufacturer Part Number:1N5418US
Manufacturer:
Product Category:Diodes - Rectifiers - Single
Available Quantity:9015 Pieces
Unit Price:Quote by Email
Description:DIODE GEN PURP 400V 3A D5B
Lead Free Status / RoHS Status:Contains lead / RoHS non-compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 1N5418US Datasheet
1N5418US´s Parameters
Internal Part Number898-1N5418US
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog Standard Diode
CategoryDiscrete Semiconductor Products
FamilyDiodes - Rectifiers - Single
ManufacturerMicrosemi Corporation
Series-
PackagingBulk
Part StatusActive
Diode TypeStandard
Voltage - DC Reverse (Vr) (Max)400V
Current - Average Rectified (Io)3A
Voltage - Forward (Vf) (Max) @ If1.5V @ 9A
SpeedFast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr)150ns
Current - Reverse Leakage @ Vr1µA @ 400V
Capacitance @ Vr, F-
Mounting TypeSurface Mount
Package / CaseE-MELF
Supplier Device PackageD-5B
Operating Temperature - Junction-65°C ~ 175°C
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement Part1N5418US
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

1N5418US is in stock for immediate shipping now. We are the distributor of Microsemi Corporation all series components. The condition of 1N5418US is new and unused, you can buy 1N5418US Microsemi Corporation with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 1N5418US.
