| Manufacturer Part Number: | 1800814230 |
|---|---|
| Manufacturer: | Molex, LLC |
| Product Category: | LED Lighting - COBs, Engines, Modules |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LED Lighting COBs, Engines, Modules LED Module Helieon, 800 QXRA White, Neutral Round |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 1800814230 Datasheet |
| Internal Part Number | 898-1800814230 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | Helieon Helieon Light Module by Molex & Bridgelux | |
| Design Resources | Lighting Product Selector | |
| Featured Product | Helieon® Sustainable Light Module Heat Sink for LED Array Holders | |
| 3D Model | 180081-4230.stp | |
| PCN Obsolescence/ EOL | 180081 Series 08/Jan/2016 | |
| Category | Optoelectronics | |
| Family | LED Lighting - COBs, Engines, Modules | |
| Manufacturer | Molex, LLC | |
| Series | Helieon, 800 QXRA | |
| Packaging | - | |
| Part Status | Obsolete | |
| Type | LED Module | |
| Color | White, Neutral | |
| CCT (K) | 4100K | |
| Wavelength | - | |
| Configuration | Round | |
| Flux @ Current/Temperature - Test | - | |
| Current - Test | 700mA | |
| Temperature - Test | - | |
| Voltage - Forward (Vf) (Typ) | 11.4V | |
| Lumens/Watt @ Current - Test | 69 lm/W | |
| Current - Max | 1.4A | |
| CRI (Color Rendering Index) | 80 | |
| Viewing Angle | 32° | |
| Features | - | |
| Size / Dimension | 80.00mm Diameter | |
| Height | 27.85mm | |
| Light Emitting Surface (LES) | - | |
| Lens Type | Flat | |
| Standard Package | 80 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 1800814230 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
1800814230 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 1800814230 is new and unused, you can buy 1800814230 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 1800814230.
