| Manufacturer Part Number: | 1776-C6815 |
|---|---|
| Manufacturer: | Caddock Electronics Inc. |
| Product Category: | Resistor Networks, Arrays |
| Available Quantity: | 9268 Pieces |
| Unit Price: | Quote by Email |
| Description: | RES NETWORK 5 RES MULT OHM 10SIP |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 1776-C6815 Datasheet |
| Internal Part Number | 898-1776-C6815 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Product Overview | |
| Featured Product | Type 1776 Decade Voltage Dividers | |
| Online Catalog | 1776 Series | |
| Category | Resistors | |
| Family | Resistor Networks, Arrays | |
| Manufacturer | Caddock Electronics Inc. | |
| Series | 1776 | |
| Packaging | Bulk | |
| Part Status | Active | |
| Circuit Type | Decade Resistor | |
| Resistance (Ohms) | 1k, 9k, 90k, 900k, 9M | |
| Tolerance | ±0.1% | |
| Number of Resistors | 5 | |
| Number of Pins | 6 | |
| Power Per Element | 62.5mW | |
| Temperature Coefficient | ±30ppm/°C | |
| Operating Temperature | -40°C ~ 85°C | |
| Applications | Voltage Divider (TCR Matched) | |
| Mounting Type | Through Hole | |
| Package / Case | 10-SIP (6 Leads) | |
| Supplier Device Package | - | |
| Size / Dimension | 1.000" L x 0.110" W (25.40mm x 2.79mm) | |
| Height | 0.550" (13.97mm) | |
| Standard Package | 50 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 1776-C6815 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
1776-C6815 is in stock for immediate shipping now. We are the distributor of Caddock Electronics Inc. all series components. The condition of 1776-C6815 is new and unused, you can buy 1776-C6815 Caddock Electronics Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 1776-C6815.
