Manufacturer Part Number: | 17211101102 |
---|---|
Manufacturer: | Harting |
Product Category: | Backplane Connectors - Hard Metric, Standard |
Available Quantity: | 9196 Pieces |
Unit Price: | Quote by Email |
Description: | 110 Position Receptacle, Female Sockets Connector 0.079" (2.00mm) Through Hole, Right Angle |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 17211101102 Datasheet |
Internal Part Number | 898-17211101102 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
3D Model | HM A angled female with shield 110 pole.stp HM A angled female with shield 110 pole.igs HM A angled female with shield 110 pole.wrl | |
Online Catalog | har-bus® HM Series | |
Category | Connectors, Interconnects | |
Family | Backplane Connectors - Hard Metric, Standard | |
Manufacturer | Harting | |
Series | har-bus® HM | |
Packaging | Bulk | |
Part Status | Active | |
Connector Type | Receptacle, Female Sockets | |
Connector Style | A 22 | |
Number of Positions | 110 | |
Number of Positions Loaded | All | |
Pitch | 0.079" (2.00mm) | |
Number of Rows | 5 | |
Mounting Type | Through Hole, Right Angle | |
Termination | Press-Fit | |
Connector Usage | CompactPCI J1/J4 | |
Contact Finish | Gold | |
Contact Finish Thickness | - | |
Current Rating | - | |
Voltage Rating | - | |
Operating Temperature | - | |
Features | Upper Shield | |
Standard Package | 10 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 17211101102 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
17211101102 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 17211101102 is new and unused, you can buy 17211101102 Harting with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 17211101102.
