163A17059X

163A17059X
Manufacturer Part Number:163A17059X
Manufacturer:
Product Category:D-Sub Connectors
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:26 Position D-Sub, High Density Plug, Male Pins Connector, Through Hole Solder
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 163A17059X Datasheet
163A17059X´s Parameters
Internal Part Number898-163A17059X
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
RoHS InformationRoHS/Reach Cert of Compliance
Online Catalog 163A Series
CategoryConnectors, Interconnects
FamilyD-Sub Connectors
ManufacturerConec
Series163A
PackagingBulk
Part StatusActive
Connector StyleD-Sub, High Density
Connector TypePlug, Male Pins
Number of Positions26
Number of Rows3
Shell Size, Connector Layout2 (DA, A) High Density
Contact TypeSignal
Mounting TypeThrough Hole
Flange FeatureMating Side (4-40)
TerminationSolder
FeaturesGrounding Indents
Shell Material, FinishSteel, Tin Plated
Contact FinishGold
Contact Finish Thickness-
Ingress ProtectionIP20
Operating Temperature-55°C ~ 125°C
Voltage Rating60V
Current Rating3A
Housing MaterialPolybutylene Terephthalate (PBT), Glass Filled
ColorBlack
Standard Package 50
Weight0.001 KG
ApplicationEmail for details
Replacement Part163A17059X
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

163A17059X is in stock for immediate shipping now. We are the distributor of Conec all series components. The condition of 163A17059X is new and unused, you can buy 163A17059X Conec with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 163A17059X.
