161H16

161H16
Manufacturer Part Number:161H16
Manufacturer:
Product Category:Power Transformers
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:XFRMR LAMINATED 24VA THRU HOLE
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 161H16 Datasheet
161H16´s Parameters
Internal Part Number898-161H16
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
CategoryTransformers
FamilyPower Transformers
ManufacturerHammond Manufacturing
Series161
Part StatusActive
TypeLaminated Core
Voltage - Primary115V
Voltage - Secondary (Full Load)Parallel 8V, Series 16V
Current - Output (Max)Parallel 3A, Series 1.5A
Primary Winding(s)Single
Secondary Winding(s)Single, Multiple Taps
Center TapNo
Power - Max24 VA
Mounting TypeThrough Hole
Termination StylePC Pin
Size / Dimension41.40mm L x 57.15mm W
Height - Seated (Max)35.05mm
Voltage - Isolation2000Vrms
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement Part161H16
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

161H16 is in stock for immediate shipping now. We are the distributor of Hammond Manufacturing all series components. The condition of 161H16 is new and unused, you can buy 161H16 Hammond Manufacturing with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 161H16.
