Manufacturer Part Number: | 15600-06-20 |
---|---|
Manufacturer: | Eaton |
Product Category: | Fuseholders |
Available Quantity: | 9029 Pieces |
Unit Price: | Quote by Email |
Description: | FUSE BLOCK BLADE 30A PANEL MNT |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 15600-06-20 Datasheet |
Internal Part Number | 898-15600-06-20 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Online Catalog | ATC 15600 Series | |
Category | Circuit Protection | |
Family | Fuseholders | |
Manufacturer | Eaton | |
Series | 15600 | |
Part Status | Active | |
Fuseholder Type | Block | |
Fuse Type | Blade | |
For Use With/Related Products | ATC, ATO | |
Fuse Size | 0.76" L x 0.207" W x 0.752" H (19.3mm x 5.25mm x 19.1mm) | |
Number of Circuits | 6 | |
Voltage | - | |
Current Rating | 30A | |
Mounting Type | Panel Mount | |
Orientation | - | |
Termination Style | Quick Connect - 0.250" (6.3mm) | |
Contact Material | Copper Alloy | |
Contact Finish | Tin | |
Standard Package | 35 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 15600-06-20 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
15600-06-20 is in stock for immediate shipping now. We are the distributor of Eaton all series components. The condition of 15600-06-20 is new and unused, you can buy 15600-06-20 Eaton with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 15600-06-20.
