13-000071

13-000071
Manufacturer Part Number:13-000071
Manufacturer:
Product Category:D-Sub Connectors
Available Quantity:9010 Pieces
Unit Price:Quote by Email
Description:7 (5 + 2 Power) Position D-Sub, Combo Plug, Male Pins Connector, Surface Mount, Right Angle Solder
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 13-000071 Datasheet
13-000071´s Parameters
Internal Part Number898-13-000071
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
RoHS InformationRoHS/Reach Cert of Compliance
CategoryConnectors, Interconnects
FamilyD-Sub Connectors
ManufacturerConec
SeriesMicroTCA™
PackagingTray
Part StatusActive
Connector StyleD-Sub, Combo
Connector TypePlug, Male Pins
Number of Positions7 (5 + 2 Power)
Number of Rows2, 2
Shell Size, Connector Layout2 (DA, A) - 7W2
Contact TypeSignal and Power
Mounting TypeSurface Mount, Right Angle
Flange FeatureMating Side, Female Screwlock (4-40)
TerminationSolder
FeaturesBoard Lock, Grounding Indents, Mounting Brackets
Shell Material, FinishSteel, Tin Plated
Contact FinishGold
Contact Finish Thickness30µin (0.76µm)
Ingress ProtectionIP20
Operating Temperature-
Voltage Rating-
Current Rating35A, 5A
Housing MaterialPolyester, Glass Filled
ColorGreen
Standard Package 20
Weight0.001 KG
ApplicationEmail for details
Replacement Part13-000071
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

13-000071 is in stock for immediate shipping now. We are the distributor of Conec all series components. The condition of 13-000071 is new and unused, you can buy 13-000071 Conec with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 13-000071.
