| Manufacturer Part Number: | 11003000301 |
|---|---|
| Manufacturer: | Harting |
| Product Category: | Heavy Duty Connectors - Frames |
| Available Quantity: | 9020 Pieces |
| Unit Price: | Quote by Email |
| Description: | FRAME ASSEMBLY FOR 2MOD |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 11003000301 Datasheet |
| Internal Part Number | 898-11003000301 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | HARTING Han-Yellock® | |
| Featured Product | Han-Yellock | |
| 3D Model | 11003000301.jt 11003000301.stp | |
| Online Catalog | Han-Yellock® Series | |
| Category | Connectors, Interconnects | |
| Family | Heavy Duty Connectors - Frames | |
| Manufacturer | Harting | |
| Series | Han-Yellock® | |
| Packaging | Bulk | |
| Part Status | Active | |
| Number of Modules | 2 | |
| Gender | Female/Male | |
| Size | - | |
| Frame Type | Assembly Module Frame | |
| Material | Polycarbonate (PC) | |
| Color | Gray | |
| Operating Temperature | -10°C ~ 85°C | |
| Includes | 1 pc - 1 Frame | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 11003000301 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
11003000301 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 11003000301 is new and unused, you can buy 11003000301 Harting with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 11003000301.
