| Manufacturer Part Number: | 1001013 |
|---|---|
| Manufacturer: | Ethertronics Inc. |
| Product Category: | RF Antennas |
| Available Quantity: | 15760 Pieces |
| Unit Price: | Quote by Email |
| Description: | 2.4GHz WLAN Chip RF Antenna 2.4GHz ~ 2.5GHz 1.2dBi Solder Surface Mount |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 1001013 Datasheet |
| Internal Part Number | 898-1001013 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | IoT Product Selector | |
| Featured Product | WLAN 802.11b/g, 2.4 GHz SMT On-Ground PCB Antenna | |
| Online Catalog | Ethertronics - Embedded | |
| Category | RF/IF and RFID | |
| Family | RF Antennas | |
| Manufacturer | Ethertronics Inc. | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Frequency Group | UHF (2 GHz ~ 3 GHz) | |
| Frequency (Center/Band) | 2.4GHz | |
| Frequency Range | 2.4GHz ~ 2.5GHz | |
| Antenna Type | Chip | |
| Number of Bands | 1 | |
| VSWR | 1.3 | |
| Return Loss | - | |
| Gain | 1.2dBi | |
| Power - Max | 2W | |
| Features | - | |
| Termination | Solder | |
| Ingress Protection | - | |
| Mounting Type | Surface Mount | |
| Height (Max) | 0.130" (3.30mm) | |
| Applications | WLAN | |
| Standard Package | 2,250 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 1001013 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
1001013 is in stock for immediate shipping now. We are the distributor of Ethertronics Inc. all series components. The condition of 1001013 is new and unused, you can buy 1001013 Ethertronics Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 1001013.
