Manufacturer Part Number:09693017172
Manufacturer:
Product Category:D-Sub Connectors
Available Quantity:9082 Pieces
Unit Price:Quote by Email
Description:17 (15 + 2 Coax or Power) Position D-Sub, Combo Receptacle, Female Sockets Connector, Free Hanging (In-Line) Solder Cup
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 09693017172 Datasheet
09693017172´s Parameters
Internal Part Number898-09693017172
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Online Catalog D-Sub
CategoryConnectors, Interconnects
FamilyD-Sub Connectors
ManufacturerHarting
Series-
PackagingBulk
Part StatusActive
Connector StyleD-Sub, Combo
Connector TypeReceptacle, Female Sockets
Number of Positions17 (15 + 2 Coax or Power)
Number of Rows2
Shell Size, Connector Layout3 (DB, B) - 17W2
Contact TypeSignal and Coax or Power (Not Included)
Mounting TypeFree Hanging (In-Line)
Flange FeatureHousing/Shell (Unthreaded)
TerminationSolder Cup
Features-
Shell Material, Finish-
Contact Finish-
Contact Finish Thickness-
Ingress Protection-
Operating Temperature-
Voltage Rating-
Current Rating-
Housing MaterialPolyester, Glass Filled
ColorGreen
Standard Package 50
Weight0.001 KG
ApplicationEmail for details
Replacement Part09693017172
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

09693017172 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 09693017172 is new and unused, you can buy 09693017172 Harting with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 09693017172.
