09670375604

09670375604
Manufacturer Part Number:09670375604
Manufacturer:
Product Category:D-Sub Connectors
Available Quantity:9018 Pieces
Unit Price:Quote by Email
Description:37 Position D-Sub Plug, Male Pins Connector, Free Hanging (In-Line) Solder Cup
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 09670375604 Datasheet
09670375604´s Parameters
Internal Part Number898-09670375604
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
3D ModelD Sub male str solder buckets 37 pins.stp
D Sub male str solder buckets 37 pins.igs
D Sub male str solder buckets 37 pins.wrl
Online Catalog D-Sub
CategoryConnectors, Interconnects
FamilyD-Sub Connectors
ManufacturerHarting
Series-
PackagingBulk
Part StatusActive
Connector StyleD-Sub
Connector TypePlug, Male Pins
Number of Positions37
Number of Rows2
Shell Size, Connector Layout4 (DC, C)
Contact TypeSignal
Mounting TypeFree Hanging (In-Line)
Flange FeatureHousing/Shell (Unthreaded)
TerminationSolder Cup
FeaturesGrounding Indents
Shell Material, FinishSteel
Contact Finish-
Contact Finish Thickness-
Ingress Protection-
Operating Temperature-55°C ~ 125°C
Voltage Rating-
Current Rating-
Housing MaterialPolybutylene Terephthalate (PBT), Polyester, Glass Filled
Color-
Standard Package 50
Weight0.001 KG
ApplicationEmail for details
Replacement Part09670375604
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

09670375604 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 09670375604 is new and unused, you can buy 09670375604 Harting with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 09670375604.
