Manufacturer Part Number: | 09670150538 |
---|---|
Manufacturer: | Harting |
Product Category: | D-Sub, D-Shaped Connectors - Backshells, Hoods |
Available Quantity: | 9015 Pieces |
Unit Price: | Quote by Email |
Description: | 15 Position One Piece Backshell Connector 180° Shielded |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 09670150538 Datasheet |
Internal Part Number | 898-09670150538 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
3D Model | Dsub metal plastic hood IP67 15poles.stp Dsub metal plastic hood IP67 15poles.igs Dsub metal plastic hood IP67 15poles.wrl | |
Online Catalog | D-Sub | |
Category | Connectors, Interconnects | |
Family | D-Sub, D-Shaped Connectors - Backshells, Hoods | |
Manufacturer | Harting | |
Series | - | |
Part Status | Active | |
Accessory Type | One Piece Backshell | |
Number of Positions | 15 | |
Cable Type | Round | |
Cable Exit | 180° | |
Shielding | Shielded | |
Material | Plastic, Metallized | |
Plating | - | |
Hardware | Assembly Hardware, Strain Relief | |
Features | Dust Tight/Waterproof (IP67), Mating Screws 4-40 | |
Color | - | |
Standard Package | 1 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 09670150538 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
09670150538 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 09670150538 is new and unused, you can buy 09670150538 Harting with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 09670150538.
