Manufacturer Part Number:09120022653
Manufacturer:
Product Category:Heavy Duty Connectors - Inserts, Modules
Available Quantity:9018 Pieces
Unit Price:Quote by Email
Description:Male Insert Gray 2 Position Screw
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 09120022653 Datasheet
09120022653´s Parameters
Internal Part Number898-09120022653
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Product Training ModulesIntroduction to Termination Types
Featured ProductHan-Modular® Connector System
3D Model09120022653.jt
09120022653.stp
Online Catalog Han® Q Series
CategoryConnectors, Interconnects
FamilyHeavy Duty Connectors - Inserts, Modules
ManufacturerHarting
SeriesHan® Q
PackagingBulk
Part StatusActive
Connector TypeInsert
GenderMale
Number of Positions2
Size3A
Termination StyleScrew
Voltage Rating400V
Current Rating40A
Contact Type-
Operating Temperature-40°C ~ 125°C
ColorGray
Housing MaterialPolycarbonate (PC)
Contact MaterialCopper Alloy
Contact FinishSilver
Material Flammability RatingUL94 V-0
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement Part09120022653
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

09120022653 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 09120022653 is new and unused, you can buy 09120022653 Harting with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 09120022653.
