Stocking distributor of Electronic Components

09061487901

09061487901
Manufacturer Part Number:09061487901
Manufacturer:
Product Category:Backplane Connectors - DIN 41612
Available Quantity:9014 Pieces
Unit Price:Quote by Email
Description:DIN-POWER F048MS-3,0C1-3
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 09061487901 Datasheet
09061487901´s Parameters
Internal Part Number898-09061487901
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
3D ModelF angled male 48 pole.stp
F angled male 48 pole.igs
F angled male 48 pole.wrl
Online Catalog DIN 41612 Series
CategoryConnectors, Interconnects
FamilyBackplane Connectors - DIN 41612
ManufacturerHarting
SeriesDIN 41612
PackagingBulk
Part StatusActive
Connector TypeHeader, Male Pins
Number of Positions48 (Power)
Number of Positions LoadedAll
Pitch0.200" (5.08mm)
Number of Rows3
StyleF
Level, Class3
Mounting TypeThrough Hole, Right Angle
TerminationSolder
Features-
Contact Finish-
Contact Finish Thickness-
Operating Temperature-
Current Rating-
Material Flammability RatingUL94 V-0
Material - InsulationThermoplastic, Glass Filled
Standard Package 20
Weight0.001 KG
ApplicationEmail for details
Replacement Part09061487901
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

09061487901 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 09061487901 is new and unused, you can buy 09061487901 Harting with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 09061487901.
