09041326921

09041326921
Manufacturer Part Number:09041326921
Manufacturer:
Product Category:Backplane Connectors - DIN 41612
Available Quantity:9178 Pieces
Unit Price:Quote by Email
Description:DIN-POWER D032MS-3,0C1-2
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 09041326921 Datasheet
09041326921´s Parameters
Internal Part Number898-09041326921
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
3D ModelD angled male 32 pole.stp
D angled male 32 pole.igs
D angled male 32 pole.wrl
Online Catalog DIN 41612 Series
CategoryConnectors, Interconnects
FamilyBackplane Connectors - DIN 41612
ManufacturerHarting
SeriesDIN 41612
PackagingBulk
Part StatusActive
Connector TypeHeader, Male Pins
Number of Positions32 (Power)
Number of Positions LoadedAll
Pitch0.200" (5.08mm)
Number of Rows2
StyleD
Level, Class2
Mounting TypeThrough Hole, Right Angle
TerminationSolder
Features-
Contact FinishGold
Contact Finish Thickness-
Operating Temperature-
Current Rating-
Material Flammability RatingUL94 V-0
Material - InsulationThermoplastic, Glass Filled
Standard Package 20
Weight0.001 KG
ApplicationEmail for details
Replacement Part09041326921
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

09041326921 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 09041326921 is new and unused, you can buy 09041326921 Harting with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 09041326921.
