| Manufacturer Part Number: | 084830 02 |
|---|---|
| Manufacturer: | Honeywell Sensing and Productivity Solutions |
| Product Category: | Keylock Switches |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | Keylock Switch 3 Position DPDT 20A (DC) 12V (DC) Panel Mount |
| Lead Free Status / RoHS Status: | Contains lead / RoHS non-compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 084830 02 Datasheet |
| Internal Part Number | 898-084830 02 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Switches | |
| Family | Keylock Switches | |
| Manufacturer | Honeywell Sensing and Productivity Solutions | |
| Series | - | |
| Part Status | Obsolete | |
| Circuit | DPDT | |
| Number of Positions | 3 | |
| Switch Function | On-Off-On | |
| Contact Timing | Not Specified | |
| Current Rating | 20A (DC) | |
| Voltage Rating - AC | - | |
| Voltage Rating - DC | 12V | |
| Actuator Type | Flat Key | |
| Key Removable Positions | 2 only | |
| Angle of Throw | 45° | |
| Contact Material | Copper | |
| Contact Finish | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Screw Terminal | |
| Panel Cutout Dimensions | Circular - 22.35mm Dia | |
| Features | - | |
| Depth Behind Flange | 39.88mm | |
| Operating Temperature | -40°C ~ 85°C | |
| Mechanical Life | 25,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 084830 02 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
084830 02 is in stock for immediate shipping now. We are the distributor of Honeywell Sensing and Productivity Solutions all series components. The condition of 084830 02 is new and unused, you can buy 084830 02 Honeywell Sensing and Productivity Solutions with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 084830 02.
