| Manufacturer Part Number: | 07111000024 |
|---|---|
| Manufacturer: | Harting |
| Product Category: | Backplane Connectors - Specialized |
| Available Quantity: | 9026 Pieces |
| Unit Price: | Quote by Email |
| Description: | MINI COAX PCRAIGHT 8PAK8 |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 07111000024 Datasheet |
| Internal Part Number | 898-07111000024 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | 07111000024.wrl 07111000024.igs 07111000024.stp | |
| Online Catalog | Mini Coax Series | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - Specialized | |
| Manufacturer | Harting | |
| Series | - | |
| Packaging | Bulk | |
| Part Status | Active | |
| Connector Usage | Backplane-to-Daughtercard | |
| Connector Type | Receptacle, Female Sockets | |
| Connector Style | Coax | |
| Number of Positions | 8 | |
| Number of Positions Loaded | All | |
| Pitch | - | |
| Number of Rows | - | |
| Number of Columns | - | |
| Mounting Type | Through Hole | |
| Termination | Press-Fit | |
| Contact Layout, Typical | 8 Coax | |
| Features | Board Guide | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Color | Natural | |
| Current Rating | 3A | |
| Material Flammability Rating | UL94 V-0 | |
| Operating Temperature | -55°C ~ 125°C | |
| Voltage Rating | - | |
| Standard Package | 16 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 07111000024 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
07111000024 is in stock for immediate shipping now. We are the distributor of Harting all series components. The condition of 07111000024 is new and unused, you can buy 07111000024 Harting with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 07111000024.
