Manufacturer Part Number: | 05ZR-8M-P |
---|---|
Manufacturer: | JST Sales America Inc. |
Product Category: | Rectangular Connectors - Free Hanging, Panel Mount |
Available Quantity: | 16871 Pieces |
Unit Price: | Quote by Email |
Description: | 5 Position Rectangular Receptacle Connector IDC Tin 28 AWG |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 05ZR-8M-P Datasheet |
Internal Part Number | 898-05ZR-8M-P | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Crimp ZH Series and IDC ZR Series 1.5MM Connectors | |
Online Catalog | ZR Series | |
Category | Connectors, Interconnects | |
Family | Rectangular Connectors - Free Hanging, Panel Mount | |
Manufacturer | JST Sales America Inc. | |
Series | ZR | |
Packaging | Bulk | |
Part Status | Active | |
Connector Type | Receptacle | |
Contact Type | Female Socket | |
Number of Positions | 5 | |
Pitch | 0.059" (1.50mm) | |
Number of Rows | 1 | |
Row Spacing | - | |
Mounting Type | Free Hanging (In-Line) | |
Fastening Type | - | |
Cable Termination | IDC | |
Wire Type | Discrete | |
Wire Gauge | 28 AWG | |
Features | Closed End | |
Contact Finish | Tin | |
Contact Finish Thickness | - | |
Color | Green | |
Standard Package | 2,000 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 05ZR-8M-P | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
05ZR-8M-P is in stock for immediate shipping now. We are the distributor of JST Sales America Inc. all series components. The condition of 05ZR-8M-P is new and unused, you can buy 05ZR-8M-P JST Sales America Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 05ZR-8M-P.
