| Manufacturer Part Number: | 0457190009 |
|---|---|
| Manufacturer: | Molex, LLC |
| Product Category: | Card Edge Connectors - Edgeboard Connectors |
| Available Quantity: | 9389 Pieces |
| Unit Price: | Quote by Email |
| Description: | CONN POWER EDGE 8POS VERT PCB |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 0457190009 Datasheet |
| Internal Part Number | 898-0457190009 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Video File | EXTreme Power | |
| RoHS Information | 45719-0009 Cert of Compliance | |
| 3D Model | 45719-0009.stp | |
| PCN Assembly/Origin | 4571y,4584y,4591y 15/Oct/2015 | |
| Online Catalog | EXTreme PowerEdge™ Series | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Manufacturer | Molex, LLC | |
| Series | Extreme Power Edge™ | |
| Packaging | Tray | |
| Part Status | Active | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | - | |
| Number of Positions | 8 (Power) | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.508" (12.90mm) | |
| Features | - | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Contact Material | Copper Alloy | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Contact Type | - | |
| Color | Black | |
| Flange Feature | - | |
| Operating Temperature | -40°C ~ 105°C | |
| Material - Insulation | Liquid Crystal Polymer (LCP) | |
| Read Out | Dual | |
| Standard Package | 510 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 0457190009 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
0457190009 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 0457190009 is new and unused, you can buy 0457190009 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 0457190009.
