| Manufacturer Part Number: | 015703.5DRT |
|---|---|
| Manufacturer: | Littelfuse Inc. |
| Product Category: | Fuses |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | FUSE BRD MNT 3.5A 125VAC/VDC SMD |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 015703.5DRT Datasheet |
| Internal Part Number | 898-015703.5DRT | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Fuseology - Introduction to Fuses | |
| Featured Product | 157 Series Fuse | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Online Catalog | NANO²® 157T Series | |
| Category | Circuit Protection | |
| Family | Fuses | |
| Manufacturer | Littelfuse Inc. | |
| Series | NANO²® 157T | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Active | |
| Fuse Type | Board Mount (Cartridge Style Excluded) | |
| Current Rating | 3.5A | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 125V | |
| Response Time | Slow | |
| Package / Case | 2-SMD, Square End Block with Clip | |
| Mounting Type | Holder/Surface Mount | |
| Breaking Capacity @ Rated Voltage | 50A | |
| Melting I²t | 26.53 | |
| Approvals | cULus, PSE | |
| Operating Temperature | -55°C ~ 125°C | |
| Color | - | |
| Size / Dimension | 0.256" L x 0.146" W x 0.154" H (6.50mm x 3.70mm x 3.90mm) | |
| DC Cold Resistance | 0.0226 Ohm | |
| Standard Package | 1,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 015703.5DRT | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
015703.5DRT is in stock for immediate shipping now. We are the distributor of Littelfuse Inc. all series components. The condition of 015703.5DRT is new and unused, you can buy 015703.5DRT Littelfuse Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 015703.5DRT.
