Manufacturer Part Number:0039301160
Manufacturer:
Product Category:Rectangular Connectors - Headers, Male Pins
Available Quantity:10419 Pieces
Unit Price:Quote by Email
Description:16 Positions Header, Shrouded Connector 0.165" (4.20mm) Through Hole, Right Angle Tin
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 0039301160 Datasheet
0039301160´s Parameters
Internal Part Number898-0039301160
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
Other Related DocumentsMini-Fit JR Color Variation
Tin Whisker Formation Change 27/Jul/2011
Product Training ModulesPower Connectors
Video FileMini-Fit Jr
RoHS Information39-30-1160 Cert of Compliance
Featured ProductMini-Fit Jr. Connectors
Power Connectors
3D Model39-30-1160.stp
0039301160 .pdf
PCN Design/SpecificationCopper/Nickel Plating 01/Aug/2011
Reflow Matte Tin Plating 27/Jul/2011
PCN Packaging00390 Series 13/Oct/2014
Online Catalog Mini-Fit Jr™ Series
CategoryConnectors, Interconnects
FamilyRectangular Connectors - Headers, Male Pins
ManufacturerMolex, LLC
SeriesMini-Fit® Jr™ 5569
PackagingBulk
Part StatusActive
Contact TypeMale Pin
Connector TypeHeader, Shrouded
Number of Positions16
Number of Positions LoadedAll
Pitch0.165" (4.20mm)
Number of Rows2
Row Spacing0.165" (4.20mm)
Contact Mating Length-
Mounting TypeThrough Hole, Right Angle
TerminationSolder
Fastening TypeLocking Ramp
FeaturesBoard Lock
Contact FinishTin
Contact Finish Thickness100µin (2.54µm)
ColorNatural
Standard Package 800
Weight0.001 KG
ApplicationEmail for details
Replacement Part0039301160
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

0039301160 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 0039301160 is new and unused, you can buy 0039301160 Molex, LLC with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 0039301160.
