Manufacturer Part Number:0022152036
Manufacturer:
Product Category:Rectangular Connectors - Headers, Receptacles, Female Sockets
Available Quantity:9719 Pieces
Unit Price:Quote by Email
Description:3 Position Receptacle Connector 0.100" (2.54mm) Through Hole, Right Angle Tin
Lead Free Status / RoHS Status:Lead free / RoHS Compliant
Moisture Sensitivity Level (MSL):1 (Unlimited)
Production Status (Lifecycle):In Production
Delivery Time:1-2 Days
Date Code (D/C):New
Datasheet Download: 0022152036 Datasheet
0022152036´s Parameters
Internal Part Number898-0022152036
Manufacturer Lead time6-8 weeks
ConditionNew & Unused, Original Sealed
RoHS Information22-15-2036 Cert of Compliance
Featured ProductKK® Interconnect Solutions
Power Connectors
3D Model22-15-2036.stp
PCN Obsolescence/ EOLResin Color 01/Jan/2002
Online Catalog KK® 4455 and 44812 Series
CategoryConnectors, Interconnects
FamilyRectangular Connectors - Headers, Receptacles, Female Sockets
ManufacturerMolex Connector Corporation
SeriesKK® 4455
PackagingTray
Part StatusActive
Connector TypeReceptacle
Contact TypeFemale Socket
Number of Positions3
Number of Positions LoadedAll
Pitch0.100" (2.54mm)
Number of Rows1
Row Spacing-
Mounting TypeThrough Hole, Right Angle
TerminationSolder
Fastening Type-
Features-
Contact FinishTin
Contact Finish Thickness100µin (2.54µm)
ColorWhite
Standard Package 1
Weight0.001 KG
ApplicationEmail for details
Replacement Part0022152036
Country of OriginUSA / JAPAN / Philippines / Malaysia
MOQ1 Piece
Picture / Image / PhotoSend via email

0022152036 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 0022152036 is new and unused, you can buy 0022152036 Molex, LLC with us at a very low price and quick delivery.

Please kindly send us an email if you have any demands for 0022152036.
