Manufacturer Part Number: | 0015311066 |
---|---|
Manufacturer: | Molex, LLC |
Product Category: | Rectangular Connectors - Headers, Male Pins |
Available Quantity: | 10893 Pieces |
Unit Price: | Quote by Email |
Description: | 6 Positions Header, Shrouded Connector 0.264" (6.71mm) Through Hole Tin |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 0015311066 Datasheet |
Internal Part Number | 898-0015311066 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
RoHS Information | 15-31-1066 Cert of Compliance | |
Featured Product | Standard .093" Pin and Socket Connectors | |
3D Model | 15-31-1066.stp 0015311066 .pdf | |
PCN Assembly/Origin | 5219 Series Housings 13/Apr/2015 | |
Online Catalog | 5219 Series | |
Category | Connectors, Interconnects | |
Family | Rectangular Connectors - Headers, Male Pins | |
Manufacturer | Molex, LLC | |
Series | 5219 | |
Packaging | Bulk | |
Part Status | Active | |
Contact Type | Male Pin | |
Connector Type | Header, Shrouded | |
Number of Positions | 6 | |
Number of Positions Loaded | All | |
Pitch | 0.264" (6.71mm) | |
Number of Rows | 2 | |
Row Spacing | 0.264" (6.71mm) | |
Contact Mating Length | - | |
Mounting Type | Through Hole | |
Termination | Solder | |
Fastening Type | Locking Ramp | |
Features | Board Lock | |
Contact Finish | Tin | |
Contact Finish Thickness | - | |
Color | - | |
Standard Package | 400 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 0015311066 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
0015311066 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 0015311066 is new and unused, you can buy 0015311066 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 0015311066.
