Manufacturer Part Number: | 0015247043 |
---|---|
Manufacturer: | Molex, LLC |
Product Category: | Rectangular Connectors - Headers, Receptacles, Female Sockets |
Available Quantity: | 11302 Pieces |
Unit Price: | Quote by Email |
Description: | 4 Position Receptacle Connector 0.165" (4.20mm) Through Hole Gold |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | 0015247043 Datasheet |
Internal Part Number | 898-0015247043 | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Power Connectors | |
Video File | Mini-Fit BMI Molex - Product of the Quarter - Mini-Fit® | |
RoHS Information | 15-24-7043 Cert of Compliance | |
Featured Product | Mini-Fit® Blind Mate Interface (BMI) Connectors Power Connectors | |
3D Model | 15-24-7043.stp | |
Online Catalog | Mini-Fit® BMI 42385 Series | |
Category | Connectors, Interconnects | |
Family | Rectangular Connectors - Headers, Receptacles, Female Sockets | |
Manufacturer | Molex, LLC | |
Series | Mini-Fit® BMI™ 42385 | |
Packaging | Tray | |
Part Status | Active | |
Connector Type | Receptacle | |
Contact Type | Female Socket | |
Number of Positions | 4 | |
Number of Positions Loaded | All | |
Pitch | 0.165" (4.20mm) | |
Number of Rows | 2 | |
Row Spacing | 0.165" (4.20mm) | |
Mounting Type | Through Hole | |
Termination | Solder | |
Fastening Type | - | |
Features | Board Lock | |
Contact Finish | Gold | |
Contact Finish Thickness | 30µin (0.76µm) | |
Color | Natural | |
Standard Package | 3,120 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | 0015247043 | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
0015247043 is in stock for immediate shipping now. We are the distributor of Molex, LLC all series components. The condition of 0015247043 is new and unused, you can buy 0015247043 Molex, LLC with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 0015247043.
